FPW-600 Heavy-Duty Steel Wire Coil Wrapping Machine
Secure loads with FPW-600 Heavy-Duty Steel Wire Coil Wrapping Machine. Feat: Automatic and semi-automatic operation modes for flexible use. Industrial grade solution.
Key Specifications
Custom Engineering Available
Need modifications? Our team can tailor this solution to your specific requirements.
Product Description
The FPW-600 is a big steel wire coil packaging machinery featuring a trolley for easy coil loading and unloading. Primarily used for packaging prestressed concrete wire and pre-strand wire coils, the FPW-600 delivers high efficiency and superior packaging. This machine reduces labor and material costs while meeting unique customer specifications.
With adjustable components and controls, the FPW-600 can be tailored to each customer's needs. Its efficient wrapping mechanisms, premium electrical components, and intelligent control system enable fast, precise, low-maintenance operation. For coil producers seeking affordable, customized steel wire packaging solutions that scale with their business, the FPW-600 is the ideal choice.
Key Benefits
- Automatic and semi-automatic operation modes for flexible use
- Compatible with various packing materials including paper, stretch film, and woven belts
- Anti-wear polyurethane friction wheels and integral mould structure for stable, safe packaging
- Adjustable ring center height for different coil outer diameters
- Customizable packing tension and overlapping rate settings
- Mechanical arm for automatic feeding and cutting of packaging material
- Optional coil size checking and scanning device for automated data input
- Coil outer diameter covering or tape applicator for sealed packaging
- Packing material clamper and cutter works with multiple material types
FPW-600 Heavy-Duty Steel Wire Coil Wrapping Machine Video
Watch our product demonstration to see the machine in action. Discover how it can improve your production efficiency and packaging quality.
Technical Specifications
| Specification | Value |
|---|---|
| Steel Wire Coil I D | 300-850 mm |
| Steel Wire Coil O D | 700-1400 mm |
| Packing Material | PVC, LLDPE, PE, Paper, HDPE, Woven (ID: 50mm, OD: 200-450mm, Width: 10-120mm) |
| Overlapping Rate | 10%-90% |
| Air Supply | 4-6 kgf/m² |
Frequently Asked Questions
Common questions about FPW-600 Heavy-Duty Steel Wire Coil Wrapping Machine and our services.
Q:What types of steel wire coils can the FPW-600 machine handle?
Q:How does the FPW-600 reduce packaging costs?
