MO-600 Fully Automatic Side Seal Shrinking Machine
MO-600 motion side seal shrinking machine offers full-automated sealing and shrinking for mass production. Features PLC control, adjustable sealing, and compatibility with POF/PE films.
Key Specifications
Custom Engineering Available
Need modifications? Our team can tailor this solution to your specific requirements.
Product Description
The MO-600 Motion Side Seal Shrinking Machine is a full-automated industrial packaging solution designed for high-volume production. It enables automatic feeding, power conveying, bagging, sealing, and shrinkage, accommodating various product heights and widths for versatile applications.
Key Benefits
- Vertical-driven transverse cutter and constant-temperature side cutter for straight, strong sealing lines.
- Thermostatic heating sealing and cutting system with hand wheel adjustment for easy operation and reliability.
- Continuous longitudinal sealing knife with unlimited product length capability.
- PLC programmable controller for smooth, continuous operation and simple maintenance.
- Electric eye detection and timer for precise film length control and consistent shrinkage effects.
- Horizontal and vertical electric eyes for easy sealing of thin or small packaging.
- Automatic scrap take-up with single motor control to prevent film damage.
- Optional automatic blowing function and front/out-feeding conveyors for customization.
MO-600 Fully Automatic Side Seal Shrinking Machine Video
Watch our product demonstration to see the machine in action. Discover how it can improve your production efficiency and packaging quality.
Technical Specifications
| Specification | Value |
|---|---|
| Sealing Type | Side sealing |
| Sealing Height | ≤250 mm |
| Product Size | Width + height ≤ 400 mm |
| Product Length | Infinite |
| Film Type | Center-folded polyolefin (POF) film or polyethylene (PE) film |
| Max Film Size | 860mm (width) x 280mm (outer diameter) |
| Tunnel Oven Size | Depends on product length |
| Tunnel Conveyor | Chains with rotating silicon coated rods |
| Working Height | 780-820 mm |
| Air Pressure | ≤0.5MPa |
| Sealing System | Special durable alloyed sealing knife with anti-stick Teflon coats |
| Operating Panel | Siemens colorful touch screen, PLC, Omron temperature controller |
Frequently Asked Questions
Common questions about MO-600 Fully Automatic Side Seal Shrinking Machine and our services.
Q:What is the main application of the MO-600 Motion Side Seal Shrinking Machine?
Q:What types of films can this machine handle?
Q:Is the machine fully automated?
Q:How is the sealing quality ensured?
Q:Can the machine be customized?
