FHOPE Automatic Steel Rod Packing Line

Name: FHOPE Automatic Steel Rod Packing Line
Brand: Industrial Solutions
SKU: 1802
Availability: InStock

Model:1802

Discover the FHOPE Automatic Steel Rod Packing Line, a fully automated system for secure packaging of steel rods. Features include film covering, weighing, labeling, and customizable options to boost productivity and protect against damage.

Key Specifications

Single Steel Rod Bundle Weight:500-2000KG

Total Power:Approx. 18KW

Installed Capacity:20KVA

Power Supply:380V, Three-phase, Five-wire

Front Infeed Conveyor Storage Capacity:3 bundles for a 260×200mm cross-section

Front Infeed Conveyor Total Storage Weight:≤6.5T

Custom Engineering Available

Need modifications? Our team can tailor this solution to your specific requirements.

Product Description

The FHOPE Automatic Steel Rod Packing Line offers an efficient and reliable solution for packaging steel rods through a fully automated process. This system ensures that each steel rod bundle is packed securely, preventing surface damage during handling and transportation. The packing line is equipped with both a film covering machine and a wrapping machine to wrap steel rods tightly, offering excellent protection against moisture, dirt, and other environmental factors.

This automated system significantly reduces manual labor, enhances productivity, and ensures consistent and precise packaging. Its customizable features make it suitable for various sizes and shapes of steel rods, providing flexibility for diverse production needs.

Key Benefits

Fully automated process for efficient steel rod packaging
Equipped with film covering and wrapping machines for secure protection
Reduces manual labor and enhances productivity
Customizable for various steel rod sizes and shapes
Includes weighing and labeling for accurate tracking

Technical Specifications

Specification	Value
Single Steel Rod Bundle Length	L1500-6000mm
Single Steel Rod Bundle Cross-section	W260-H200mm
Hydraulic Oil	46# Anti-wear Hydraulic Oil
Air Supply	6-8 kgf/c㎡
Front Infeed Conveyor Transfer Speed	Approx. 5-8 M/min
Front Lifting Conveyor Transfer Speed	Approx. 5-8 M/min
Front Roller Conveyor Conveying Speed	Approx. 5-8 M/min
Front Roller Conveyor Weighing Capacity	≤2000kg
Front End Film Covering Machine Film Material Width	800-900mm
Wrapping Machine A Packaging Material	PE stretch film
Rear End Film Covering Machine Film Material Width	800-900mm
Knit Belt Wrapping Machine Slip Ring Speed	Max 100 r/min

Frequently Asked Questions

Common questions about FHOPE Automatic Steel Rod Packing Line and our services.

Q:What is the main benefit of the FHOPE Automatic Steel Rod Packing Line?

The main benefit is its fully automated process, which reduces manual labor, enhances productivity, and ensures secure packaging to prevent damage during handling and transportation.

Q:What types of steel rods can this packing line handle?

This packing line is customizable and can handle steel rods with lengths from 1500 to 6000mm, weights from 500 to 2000KG, and cross-sections of W260-H200mm, making it suitable for various sizes and shapes.

Q:How does the system protect steel rods during packaging?

The system uses film covering and wrapping machines to tightly wrap steel rods, providing excellent protection against moisture, dirt, and other environmental factors, ensuring secure packaging.
